l The controller device lock key protecting from misoperation.
l The Table is made of penetrated X ¨C ray material.There is cassette guide rail under the table which make radiography.
l The table is fixed a button which can control the electric wheel to draw in and put out so that the table can be pulled easily.
l Accessories and Guide rail are made of stainless steel,polyurethane etc material.
l The main accessory hydraulic pump and electromagnetic valve are made of imported component from Taiwan.
l The mattress is made of foam polyurethane,acid and alkali resistance,high temperature resistance and easy clean.
l The head board and leg board are adopted special imported gas-spring from Germany.it is convenient to operate.
Main specification parameters
Item |
Contents |
Length and width of table |
2000mm x 480mm |
Max.&Min.Height of table |
930mm x 690mm |
Max.degree of forward and backward tilting of table |
forward ¡Ý25o backward ¡Ý20o |
Max.degree of left and right tilting of table |
left ¡Ý18o right ¡Ý18o |
Range of leg rest adjustment |
down ¡Ý90o detachable |
Range of back rest adjustment |
up ¡Ý75o down ¡Ý10o |
Range of head rest adjustment |
up ¡Ý45o down ¡Ý50o detachable |
Elevating height of kidney bridge |
¡Ý80mm | |
